1.2G/1.3G image transmission 2W VTX VRX model aircraft UAV FPV transmitter long-distance high-sensitivity receiver-Wholesale Disccount

Description

1.2G/1.3G-2W VTX Selected high-strength aluminum alloy CNC shell to assist heat dissipation, unique appearance design, stronger impact resistance and better heat dissipation performance.
7-36V wide voltage input, with temperature control protection function to prevent overheating and burning. Support 30.5×30.5mm (M3) installation hole position.

Features

1. Three adjustable power levels, up to 2000mW, suitable for long-distance flight
2. 9 optional channels
3. Selected high-strength aluminum alloy CNC shell, auxiliary fan heat dissipation
4. Wide voltage input, support 7-36V volts
7. With temperature control protection function to prevent high temperature burnout
8. Support 30.5×30.5mm (M3) installation holes

Parameters

Product name: 1.2G/1.3G 2W VTX image transmission
Size: 40×27.5x13mm
Installation hole: 30.5×30.5mm (M3)
Frequency band: 1080MHz-1360MHz
Number of channels: 9
Frequency: 1080/1120/1160/1200/1240/1280/1320/1360/1220 (MHz)
Output power: 25mW800mW/2000mW/Pit mode
Frequency stability: ±100KHz (Typ.)
Frequency accuracy: ±200KHz (Typ.)
Signal-to-noise ratio S/N (Fo±3MHz): >70dBc
Antenna port impedance: 50 Ohms
Input voltage: DC7-36V (2-8S Battery)
Output voltage: 5V@600mA
Antenna interface: MMCX
Cable interface: sh1.25 6pin
Video format: PAL/NTSC
Operating temperature: -10℃~+60℃
Weight: 22g (only for image transmission)

Precautions

1. Install the antenna before use.
2. If the image transmission is overheated, the temperature control protection will be activated and the power will be automatically reduced. Please ensure good ventilation and heat dissipation when using it.
3. The 5V output is only used for the camera. It is forbidden to connect the power input to the 5V output port, otherwise the image transmission will be damaged.
